Automatic Transfer Switch (ATS) :

An Automatic Transfer Switch (ATS) is an intelligent power switching device that automatically transfers the electrical load from the main power source to a backup power source when it detects a failure, outage, or abnormal voltage in the main power supply.

Smart ATS PDU :

The Smart ATS PDU is a power distribution device designed to provide uninterrupted power to connected equipment by automatically switching between two power sources. It supports dual input circuits, enabling seamless transfer of power if the primary source fails. This ensures high reliability for sensitive or critical loads. With IP Power function, the user can allows remote control of critical equipment with just a few clicks via smartphone or web browser. Commands can also be set up by scanning a QR code through QR code scanner.

Features: Smart ATS PDU

Common:
Redundant Protection
When main power fails, it will automatically switch to backup power.
Multidevice control
User can control the ATS PDU through WAN and LAN.
Surge Protection
The breaker automatically trips during power overload or lightning events to ensure electrical safety
Power Measurement
Voltage, current measurement can help user monitor the ATS PDU status.
Temperature Detection
The ATS PDU has a thermometer can monitoring and detect temperature.
Mail notification
Notify user when outlet trigger the action,support SNMP and TLS.
External extension support
Support UPS management and QR code scanner
Mobile App remote control
User can monitor and remote control ATS PDU through AVIOSYS IP Power App (iOS/Android support)

ATS 9050

  • -Automatic Transfer Switch(ATS)
  • -Dual Redundant Power input
  • -Maintains system comm. and status logs
  • Active surge filter
  • 100~240VAC Input Max 15 A
  • 2x C14 inlet
  • 4x C13/NEMA5 outlet
  • E Ink display monitor
  • 4x Ammeter
  • 2 Voltmeter
  • 1x Thermometer
  • 2x RJ45 Ethernet
  • 1x DI, 2x USB Port

  • HTTP HTTPS Web Server CGI
  • IPv4 IPv6 mDNS
  • CGI/CNT/MQTT
  • SNMPv1 v2 v3
  • EAPOL(IEEE802.1x)
  • SSL
  • Mail and Voice notification
  • Option Model wireless

ATS 9050 Lite

  • -Automatic Transfer Switch(ATS)
  • -Dual Redundant Power input
  • Active surge filter
  • 100~240VAC Input Max 15 A
  • 2x C14 inlet
  • 4x C13/NEMA5 outlet
  • 1 total Ammeter
  • 2x Voltmeter
  • 1x Thermometer
  • 1x RJ45 Ethernet
  • 1x USB Port

  • HTTP HTTPS Web Server CGI
  • IPv4 IPv6 mDNS
  • CGI/CNT/MQTT
  • SNMPv1 v2 v3
  • EAPOL(IEEE802.1x)
  • SSL
  • Mail and Beeper notification
  • Option Model wireless

ATS 9820

  • -Automatic Transfer Switch(ATS)
  • -Dual Redundant Power input
  • -Maintains system comm. and status logs
  • Active surge filter
  • 100~240VAC Input Max 15 A
  • 2x C14 inlet
  • 8x C13/NEMA5 outlet
    (2 set of 4-outlet ATS function)
  • 1U-rack size
  • E Ink display monitor
  • 8x Ammeter
  • 2x Voltmeter
  • 1x Thermometer
  • 2x RJ45 Ethernet
  • 1x DI, 2x USB Port

  • HTTP HTTPS Web Server CGI
  • IPv4 IPv6 mDNS
  • CGI/CNT/MQTT
  • SNMPv1 v2 v3
  • EAPOL(IEEE802.1x)
  • SSL
  • Mail and Voice notification
  • Option Model wireless

ATS 9820 Lite

  • -Automatic Transfer Switch(ATS)
  • -Dual Redundant Power input
  • Active surge filter
  • 100~240VAC Input Max 15 A
  • 2x C14 inlet
  • 8x C13/NEMA5 outlet
    (2 set of 4-outlet ATS function)
  • 1U-rack size
  • 1 total Ammeter
  • 2x Voltmeter
  • 1x Thermometer
  • 1x RJ45 Ethernet
  • 1x USB Port

  • HTTP HTTPS Web Server CGI
  • IPv4 IPv6 mDNS
  • CGI/CNT/MQTT
  • SNMPv1 v2 v3
  • EAPOL(IEEE802.1x)
  • SSL
  • Mail and Beeper notification
  • Option Model wireless
